REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 6
Page 17
December 01/2010
4.3) Installation of carburetor and intake silencer
Safety instruc-
tions
See Figure 10.
NOTES: On assembly, make sure that all pipes are correctly con-
nected.
Preparation The following preparation is required before installation:
Installation of the fuel pump
Instructions Proceed as follows to install the carburetor and intake silencer:
Danger of explosion and ignition!
Overflowing and split gasoline must be absorbed im-
mediately with a binding agent and correctly disposed
of. Do not work with open flames and sources of igni-
tion. Fuel must not be allowed to come into contact
with hot engine parts and components.
Step Procedure
1 Install the fuel pump with 2 cyl. M6x20 screws and new locknuts on the bottom
of the bracket for the intake silencer.
NOTE: The fuel pump must be installed to the connection for the
impulse points down and the connection for the fuel feed
points towards the driver's seat.
Step Procedure
1 Position the carburetor (1) on the carburetor flange (2).
2 Pull the hose clamp (3) over the carburetor flange and tighten it.
3 Fasten the intake silencer (4) to the carburetor with the hose clamp.
4 Fasten the intake silencer to the support bracket (5).
5 Check the carburetor cable in the elbow for wear.
6 Connect the fuel feed line (6) and the cable (7) to the carburetor.
7 Connect the impulse pipe (8).
