DK00025.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 3
Page 5
December 01/2010
2) Preparation
Safety
instructions
NOTES: When disconnecting the battery leads proceed as follows
- first disconnect the negative pole, then the positive pole.
Remember that the ignition unit is under high voltage
(35 kV) during operation, therefore removal of the spark
plug lead during operation is not permissible.
Special tools The following special tools and equipment are required:
2.1) Dismantling the exhaust system
Instructions See Figure 2.
Proceed as follows to dismantle the exhaust system:
Danger of serious burns and scalding!
Allow engine to cool to ambient temperature before
starting work.
Danger of electric shock!
Switch off ignition and remove the ignition key. Dis-
connect the negative battery terminal.
Part number Description Use
Part no. 251680 Spring hook Tension spring
Step Procedure
1 Disconnect tension springs (1) with spring hooks (part no. 251680).
2 Loosen the nuts (2) on the shock mountings and remove the exhaust system.
