DK00027.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 5
Page 14
December 01/2010
3.3) Conrod set - Repair set
3.3.1) Disassemble crankshaft
Safety
instructions
See Figure 8 to Figure 10.
NOTES: Before disassembly clean the crankshaft thoroughly with a
cleaning agent (grease-free).
Special tools The following special tools and equipment are required:
Non-compliance can result in serious injury or death!
Be particularly careful when working with a tool such
as a press, and also observe the directions of the
manufacturer of the tool.
Repair of the crankshaft requires a special tool and
must only be carried out by workshops with the
appropriate experience and equipment.
The parts in the repair set are paired together and
must therefore be exclusively used together.
Part number Description Use
n.e. Press Crankshaft
n.e. Dial gauge
Part no. 276050 Repair kit Crankshaft
