DK00029.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 7
Page 8
December 01/2010
Figure 4 K00079,K00151,K00112
2.3.1) Removal of the sprocket
Special tools The following special tools and equipment are required:
Instructions See Figure 5.
4 Thrust washer
5 Clutch drum
6 Sprocket
7 Needle cage
8O-ring
9 Thrust washer
Part Function
Part number Description Use
Part no. 944231 Fixation tool for sprocket
(old model)
Clutch drum
Part no. 277362 Fixation tool for sprocket Clutch drum
Step Procedure
1 Method 1: fix fixation tool for sprocket (1) (part no. 944231) in a vise in the area
of the flat iron.
2 Position the clutch drum (3) with installed sprocket (4) on the centering man-
drel of the fixation tool for sprocket so the clutch bell is fixed by the fixation tool.
3 Unscrew the hex nut (5) for the sprocket.
4 Remove the sprocket from the clutch drum.
5 Method 2: fix fixation tool for sprocket (2) (part no. 277362) in a vise.
6 Insert clutch drum (3) with installed sprocket (4) into the corresponding
toothed cutout.
7 Unscrew the hex nut (5) for the sprocket.
8 Remove the sprocket from the clutch drum.
