DK00031.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 9
Page 5
December 01/2010
2) Removal of the exhaust system
Safety
instructions
Preparation The following preparation is required before removal:
2.1) Checking the exhaust system
Instructions See Figure 2.
2.2) Disassembling the exhaust system
General NOTES: If the exhaust system noise increases, then the silencer
baffle mat should be replaced.
Instructions See Figure 2.
,
Danger of serious burns and scalding!
Allow engine to cool to ambient temperature before
starting work.
Step Procedure
1 Removal of the exhaust system. See also Chap. 3 Section: 2.1).
Step Procedure
1 Check exhaust system (1) for cracks.
2 Clean the ball socket (2) of combustion residue and inspect for wear.
3 Check that the cover rivets (3) are tightly seated.
Step Procedure
1 Drill out the rivets of the cover (3).
2 Remove old silencer baffle mat (4).
To Next Page
