3.3) Installation of the fuel line
Safety
instructions
Instructions Proceed as follows to install the fuel hose:
3.4) Installation of the carburetor cable
Instructions Proceed as follows to install the cable bowden:
Danger of explosion and ignition!
Overflowing and spilt gasoline must be absorbed im-
mediately with a binding agent and correctly disposed
of. Do not work with open flames and sources of igni-
tion. Fuel must not be allowed to come into contact
with hot engine parts and components.
Step Procedure
1 The installment of the fuel line is identical to removal in reverse order. See also
Chap. 3 Section: 2.3).
Step Procedure
1 The installment of the cable bowden is identical to removal in reverse order.
See also Chap. 3 Section: 2.4).
