DK00029.fm
REPAIR MANUAL
BRP-Powertrain
Effectivity: 125 MAX/125 Junior MAX/125 Mini
MAX/125 Micro MAX
Edition 2 / Rev. 0
Chapter 7
Page 9
December 01/2010
Graphic
Sprocket
Figure 5 K00144,K00022
Part Function
1 Fixation tool for sprocket (old model)
2 Locating/locking device
3 Clutch drum
4 Sprocket
5Hex nut
1
4
3
5
Centering mandrel for
sprockets with 12, 13, and
14 teeth
Locking tool for clutch bell
Centering mandrel for
sprockets with 11 teeth
2
