Effectivity: 914 Series
Edition 2 / Rev. 0
d04282
page 109
July 01/2008
BRP-Rotax
INSTALLATION MANUAL
19.2) Wiring diagram
(See Fig. 69)
Legend to wiring diagram (Fig. 69)
Items 1-20, 52-54 are included in the standard volume of supply of the engine
Items 21-25 are available as accessory
Items 30-51 can't be supplied by BRP-Rotax
▲ WARNING: The certification of items/components which are not included in the
standard volume of supply of engine has to be conducted by the
aircraft manufacturer to the latest requirements such as FAR or
EASA.
1 36 pole plug receptacle
2-3 plug connection for pressure sensor
4 plug connection for lamps
5 plug connections for servo motor + 5.1 for potentiometer
6 pressure sensor (static pressure, atmospheric pressure)
7 pressure sensor (airbox - already wired in advance)
8 servo motor + 8.1 potentiometer
9 2 electronic modules (A and B)
10-11 plug connection for ignition switch
12 integrated generator
13-14 external regulator - rectifier with plug connections
15 electric starter
16-17 starter relay with plug connection
18-19 electric fuel pumps
20 3-way solenoid valve (float valve pressure - already wired in advance)
21-23 external alternator with connections
24 electric rev-counter
25 capacitor
30-31 lamps
32 isolating switch for servo motor
33 2 ignition switches
34 master switch
35 starter switch
36 control lamp
37 amperemeter
38 battery relay
39 battery
40 bus bar
41 capacitor
42-51 circuit breaker
52 plug connection for airbox temprature sensor
53 airbox temperature sensor (already wired in advance)
54 plug connection for trigger coil assy.
55 trigger coil assy. (speed)
56 plug connection for throttle positioning sensor
57 throttle positioning sensor (already wired in advance)
58 relay
