Rotax 914 series Installation Manual

page 122
July 01/2008
Effectivity: 914 Series
Edition 2 / Rev. 0
d04282
INSTALLATION MANUAL
BRP-Rotax
19.4.10)Boost lamp
See Fig. 69.
- colour of lamp: red or colour as per effective regulations.
- voltage: 12 V(DC)
depending on input voltage of TCU.
- current: max. 0,5 A
- connections:
+ terminal: flexible wire 0,75 mm
2
(18 AWG) white No. 10*
- terminal:flexible wire 0,75 mm
2
(18 AWG) white No. 28*
* from the 36 pole plug receptacle of the TCU, plug 6,3 x 0,8 to DIN 46247
- length approx. 600 mm (24 in) from TCU
■ CAUTION: Do not connect the - (neg.) terminal to ground or the + (pos.)
terminal to bus (12 volt), each wire must be connected directly
to the lamp. Use a two wire lamp; do not use a lamp that
grounds through the base as this will defeat the warning
system.
19.4.11)Caution lamp
See Fig. 69.
- Colour of lamp: orange or colour as per effective regulations.
- Voltage: 12 V(DC)
depending on input voltage of the TCU
- current: max. 0,5 A
- connections:
+ terminal: flexible wire 0,75 mm
2
(18 AWG) white No. 35*
- terminal:flexible wire 0,75 mm
2
(18 AWG) white No. 11*
* from the 36 pole plug receptacle of the TCU, plug 6,3 x 0,8 to DIN 46247
- length approx. 600 mm (24 in) from TCU
■ CAUTION: Do not connect the - (neg.) terminal to ground or the + (pos.)
terminal to bus (12 volt), each wire must be connected directly
to the lamp. Use a two wire lamp; do not use a lamp that
grounds through the base as this will defeat the warning
system.

Rotax 914 series Specifications

General

Bore	79.5 mm
Stroke	61 mm
Compression Ratio	9.0:1
Cooling System	Liquid-cooled cylinder heads, air-cooled cylinders
Redline	5800 rpm
Engine Type	4-cylinder, 4-stroke
Fuel Type	Avgas 100LL
Oil System	Dry sump
Fuel System	fuel injection
TBO (Time Between Overhauls)	2000 hours
Displacement	1.211 liters (1211 cc)
Power Output	84.6 kW (115 hp) at 5, 800 rpm
