page 28
July 01/2008
Effectivity: 914 Series
Edition 2 / Rev. 0
d04275
INSTALLATION MANUAL
BRP-Rotax
8.2) Installation dimensions (all dimensions in mm)
See Fig. 2/3/4.
◆ NOTE: Dimensions to point of reference (P).
8.3) Weights
Weight of engine defined to the following conditions:
- Engine dry from serial production with int. alternator, with overload clutch,
without fuel pumps (see section Description of design)
ROTAX 914 F, 914 UL
Engine weight ..... configuration 2 and 4: ..........................71,7 kg (158 lb)
configuration 3: ....................................74,4 kg (164 lb)
auxiliary equipment:
Weight of ............ external generator assy. ....................... 3,0 kg (6.6 lb)
overload clutch ...................................... 1,7 kg (3.7 lb)
vacuum pump assy. ............................ 0,8 kg (1.76 lb)
hydraulic governor assy. incl. drive (depending on type)
............................. aprrox. 2,2 (4.8 lb) to 2,7 kg (6 lb)
HD-starter ........................... additional + 0,43 kg (1 lb)
rectifier regulator ................................0,3 kg (0.66 lb)
starter relais ...................................0,145 kg (0.32 lb)
radiator ...............................................1,0 kg (2.2 lb)
cooling air duct ...................................0,8 kg (1.76 lb)
air filter ............................................0,15 kg (0.33 lb)
oil radiator .........................................0,6 kg (1.3 lb)
Standard engine version
pos. (+) neg. (-) total
max. dimension in x-axis (mm) 8,5 -656,6 665,1
max. dimension in y-axis (mm) 288 -288 576,0
max. dimension in z-axis (mm) 220 -311 531,0
04858
