page 64
July 01/2008
Effectivity: 914 Series
Edition 2 / Rev. 0
d04278
INSTALLATION MANUAL
BRP-Rotax
Lubrication circuit engine (main oil pump)
oil tank (outlet) to the oil cooler
oil cooler to the oil pump (inlet)
oil return to the oil tank (inlet)
oil tank to the venting line
Oil circuit turbo charger (suction pump)
oil return to the oil tank (inlet)
◆ NOTE: In the serial version of the engine an oil tank is included, but no
provision is made for attachment of an oil cooler.
▲ WARNING: Certification of oil cooler and connections to the latest requirements
such as FAR and EASA has to be conducted by the aircraft
manufacturer.
13.2) Limits of operation
▲ WARNING: The lubrication system has to be designed such that operating
temperatures will not exceed the specified limits.
Oil pressure: For oil pressure sensor see Fig. 93/94.
see OM 914 Serie, section 10.1
Oil temperature: Oil temperature sensor, see Fig. 91/92.
see OM 914 Serie, section 10.1
▲ WARNING: At operation below nominal oil temperature formation of condensate
in the lubrication system might influence oil quality.
◆ NOTE: For operation at low temperatures the installation of an oil thermo-
stat, parallel to the oil cooler, is strongly recommended.
Advantages: safe oil pressure after cold start, prevention of fuel and
water accumulation in the oil.
See therefore SL-914-009 "Use of an oil thermostat", latest issue.
