Rotax 914 series Installation Manual

Effectivity: 914 Series
Edition 2 / Rev. 0
d04280
page 93
July 01/2008
BRP-Rotax
INSTALLATION MANUAL
15.2) Connections for Bowden-cable actuation and limit load.
See Fig. 55/56.
- connection for throttle actuation (1)
connection on throttle lever: set screw M 5x12
tightening torque: 4 Nm (35 in.lb)
(suitable for 1,5 mm (.06 in.) steel wire)
action travel: 65 mm (2
1
/
2
")
actuating force: min. 1,5 N (.3 lb)
max. 8 N (1,8 lb)
limit load: 20 N (4,5 lb)
◆ NOTE: Throttle opens by spring.
- connection for starting carb (choke) actuation (2)
connection on choke lever: clamping nipple 6
(suitable for 1,5 mm (.06 in.) steel wire)
action travel: 23 mm (
15
/
16
")
actuating force: min.10 N (2,2 lb)
max. 45 N (10 lb)
limit load: 100 N (22 lb)
Directive for choke actuation
The choke shaft (3) is marked (4). This mark has to point towards cable engagement
(5).
5,2
0,21 in.
2,2
0,09 in.
ø 6,7 ø 0,26in.
Fig. 56
05089
2
3
4
5
Fig. 55
08415
1
2

Rotax 914 series Specifications

General

Bore	79.5 mm
Stroke	61 mm
Compression Ratio	9.0:1
Cooling System	Liquid-cooled cylinder heads, air-cooled cylinders
Redline	5800 rpm
Engine Type	4-cylinder, 4-stroke
Fuel Type	Avgas 100LL
Oil System	Dry sump
Fuel System	fuel injection
TBO (Time Between Overhauls)	2000 hours
Displacement	1.211 liters (1211 cc)
Power Output	84.6 kW (115 hp) at 5, 800 rpm
