Rotax 914 series - Air Temperature in the Airbox (Optional)

page 138
July 01/2008
Effectivity: 914 Series
Edition 2 / Rev. 0
d04283
INSTALLATION MANUAL
BRP-Rotax
23.6) Air temperature in the airbox (optional)
See Fig. 98.
To take air temperature readings in the airbox a connection is provided. This connection
is closed on the standard engine by a plug screw.
- connection: tapping 1/8-27 NPT
thread length approx. 9 mm (3/8")
Fig. 98
05740
1
