page 32
July 01/2008
Effectivity: 914 Series
Edition 2 / Rev. 0
d04275
INSTALLATION MANUAL
BRP-Rotax
9.4) Protective covering
All openings are protected against ingress of contamination and dampness. It is
recommended not to remove these plugs until installation of the specific feed line.
◆ NOTE: If the engine will be sent to the manufacturer or distributor reuse
transport equipment and replug openings.
List of protective covering:
- exhaust socket: ............................................. 1x cone plug
- air intake socket on turbo: ............................ 1x cover
- connection for manifold pressure: ................. 1x cap
- fuel pressure control (in-and outlet): ............. 1x each cap
- oil supply and oil discharge: .......................... 1x each cap
- oil return (turbo): ........................................... 1x cap
- supply and discharge of coolant: .................. 1x each cone plug
- propshaft on configuration 3: ........................ 1x disk plug or cap
- airbox: ........................................................... 2x cap
▲ WARNING: Protective covering to be utilized for transport and at engine installation
only. Before engine operation remove these protections.
