page 6
July 01/2008
Effectivity: 914 Series
Edition 2 / Rev. 0
d04273
INSTALLATION MANUAL
BRP-Rotax
21) Vacuum pump .................................................................................................... 129
21.1) Technical data ....................................................................................................... 129
22) Hydraulic governor for constant speed propeller .......................................... 131
22.1) Technical data ........................................................................................................ 131
23) Connections for instrumentation .................................................................... 133
23.1) Sensor for cylinder head temperature ..................................................................... 133
23.2) Sensor for oil temperature ...................................................................................... 134
23.3) Oil pressure sensor ................................................................................................ 135
23.4) Mechanical rev-counter (tach drive)........................................................................ 136
23.5) Monitoring of the intake manifold pressure ............................................................. 137
23.6) Air temperature in the airbox (optional) ................................................................... 138
24) Preparations for trial run of engine ................................................................. 139
