Roxell FLEX-AUGER FA 75 - Page 129

ROXELL - 031 - 0516
FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-31
FIGURE 47.
TIGHTEN BOLT : MINIMUM 10 Nm.
MODEL 90
Slide a tube 90mm into the tube anchor weldment.
FIGURE 48.
MODEL
125
TIGHTEN BOLT : MINIMUM 10 Nm.
Slide a tube 120mm into the tube anchor weldment.
03701196
