FLEX-AUGER - INSTALLATION INSTRUCTIONS
III-66
FIGURE 132.
2. Always put 1 manual outlet model 125 with
shut-off just after the mixing point. This is need-
ed for calibration. This outlet must have a 100%
drop out. See fig. 28. page III-15.
Mixing point
100% drop out
Ø108MM
A
FLEX-AUGER I : AUGER MODEL 90 FROM BIN TO CONTROL UNIT. NO AUGER MODEL 125 NEEDED !!!
