4.3 Suspending measuring mat in storage compartment
The monitor's storage compartment contains the following functional ele-
ments:
• inductive charging interface: for charging the measuring mat recharge-
able battery
• infrared interface: for communicating between the monitor and the
measuring mat
ATTENTION
Malfunction
The measuring mat rechargeable battery can only be charged by
the inductive charging interface in the storage compartment of the
monitor.
► After each measurement, suspend the measuring mat back in the
storage compartment of the monitor. This ensures that the measur-
ing mat rechargeable battery is always adequately charged.
Store the measuring mat in the storage compartment of the monitor when
you are not performing a measurement.
1. Fold up the measuring mat as shown in the illustration below.
2. Suspend the measuring mat in the storage compartment as shown in the
illustration below.
3. Ensure that the magnetic catch of the measuring mat is correctly located
on the magnetic catch of the storage compartment.
