198
Using the Configurator
• Double-click in the CPU column to change the CPU address.
• Double-click in the Tag column to change the tag.
19.42 Loop Details
The loop details displays the hard wired (conventional) circuits or addressable devices in a
loop.
To see the loop details
1. In the Job Tree, click the loop that you want to see under the Loop Adder or Audio
Control.
Table 27 Loop Details
Name Description
Addr
For regular addressable devices, this address is the same as the device
address. For conventional circuits display adder & circuit on adder.
Device
Conventional - fixed, depending on the circuit adder. See section 19.14 on
page 168.
Addressable - chosen when adding devices. Can be edited conditionally.
For example, a Photo Detector can be changed to other types of detector,
a Relay Opt module can be changed to a Supv. Opt module.
Other changes can be made only by deleting the device and adding
another.
Type The process type of the device. You can change this by double-clicking it.
SubType
The specific subtype of the device. For instance, a photo detector can be a
smoke, beam, or duct detector.
The SubType helps identify the device to OpenGN. In OpenGN, you can
assign an icon to the device based on the Type or SubType. In the
OpenGN Event List, the SubType appears in the Object Description
column.
Sens Lvl Pre
On addressable loops, the pre-alarm (or for some device types the trouble)
sensitivity level.
Sens On addressable loops, the alarm level 1 sensitivity level.
Sens Lvl 2 On addressable loops, the alarm level 2 sensitivity level.
Sens Lvl 3 On addressable loops, the alarm level 3 sensitivity level.
Sens B Lvl
Pre
On addressable loops, the after hours and night time pre-alarm (or for
some device types the trouble) sensitivity level.
Sens B
On addressable loops, the after hours and night time alarm level 1
sensitivity level.
Sens B Lvl 2
On addressable loops, the after hours and night time alarm level 2
sensitivity level.
Sens B Lvl 3
On addressable loops, the after hours and night time alarm level 3
sensitivity level.
