Kingfisher Plus+ Hardware Manual
Kingfisher Plus+ RTU Components
Each RTU requires a Processor module installed into a backplane and a Power Supply
source as a minimum. Communications and I/O modules are optional. The modules that are
currently available are listed below:
Module Description
BACKPLANES
BA-4-PLUS Backplane, 4-slot (for PC-1 processor only)
BA-40-PLUS Backplane, 4-slot
BA-6-PLUS Backplane, 6-slot
BA-12-PLUS Backplane, 12-slot
BP-2-PLUS Backplane with integrated 5 V power supply, 2-slot
BP-4-PLUS Backplane with integrated 5 V power supply, 4-slot
BP-6-PLUS Backplane with integrated 5 V power supply, 6-slot
POWER SUPPLIES
PS-12-0
AC-DC Power Supply Module
Input 100-240 V
AC
/ 50-60 Hz
PS-22-0
DC-DC Power Supply Module
Input 20-60 V
DC
PS-12-C
AC-DC Power Supply Module
Input 100-240 V
AC
/ 50-60 Hz, additional 24 Volt Auxiliary Output
PS-22-C
DC-DC Power Supply Module
Input 20-60 V
DC
, additional 24 Volt Auxiliary Output
PSU-3
AC-DC Power Supply Unit
Input 90-260 V
AC
/ 50-60 Hz, 40 W
PSU-4
AC-DC Power Supply Unit
Input 90-260 V
AC
/ 50-60 Hz, 60 W
PSU-5
AC-DC Power Supply Unit
Input 90-260 V
AC
/ 50-60 Hz, 70 W
PROCESSOR MODULES
PC-1
Power and Processor Module
Integrated Power Supply, 16 MHz 16-bit CPU, Fixed Serial Port + 1x Optional Port
CP-12
Processor Module
40 MHz 16-bit CPU, Fixed Serial Port + 2x Optional Ports
CP-30
Processor Module
166 MHz 32-bit CPU, Fixed Ethernet Port + 2x Optional Ports
COMMUNICATIONS MODULES
MC-12
Communications Module
up to 3 communications ports (incl. fixed serial port)
MC-31
Communications Module
up to 3 communications ports (incl. fixed Ethernet port)
Hardware Manual Version 7.16
