semaphore KINGFISHER PLUS+ - Page 15

Kingfisher Plus+ Hardware Manual
Module Description
ANALOGUE MODULES
AI-1
Analogue Input Module
8 analogue current inputs, 1 common per module
AI-10
Analogue Input Module
8 analogue high impedance inputs, 1 common per module
AO-3
Analogue Output Module
4 analogue 0-20 mA / 4-20 mA outputs, 4 commons per module
DIGITAL MODULES
DI-5
Digital DC Input Module
Bipolar dry contact inputs, 16 Points, 1 common per module
DI-10
Digital AC/DC Input Module
Intelligent AC/DC inputs, 16 Points, 1 common per module
DO-1
Digital Relay Output Module
NO/NC (SPDT), 8 Points, 4 commons per module
DO-2
Digital Relay Output Module
NO (SPST), 16 Points, 2 commons per module
DO-6
Digital Solid State Module
Open Drain Outputs, 16 Points, 2 commons per module
I/O MODULES
IO-2
Combination Digital I/O Module
8 digital inputs / 8 digital outputs, 2 commons per module
IO-3
Combination Analogue/Digital I/O Module
4 relay outputs / 4 analogue inputs / 4 digital inputs / 1 analogue output, 4 commons per
module
IO-4
Combination Analogue/Digital I/O Module
2 relay outputs / 2 analogue inputs / 8 digital inputs, 3 commons per module
IO-5
Combination Analogue/Digital I/O Module
4 analogue inputs / 1 analogue output / 4 digital inputs / 4 sinking outputs, 4 common per
module
EXPANSION BOARDS
TEL REL 002
SPDT Relay Expansion Board
16 SPDT relay outputs, 1 common per channel
TEL REL 003
SPST Relay Expansion Board
16 SPST relay outputs, 1 common per channel
TEL REL 004
DPDT Relay Expansion Board
16 DPDT relay outputs, 2 commons per channel
Hardware Manual Version 7.16
