Kingfisher Plus+ Hardware Manual
Digital Output Example
Driving external load(s) from
digital output(s)
Notes:
1. Polarity can be reversed.
2. For safety reasons, do not connect more than one power source to a Digital Out Common
terminal.
LOAD Z
LOAD Y
Channel Z
Channel Y
Common
Power
Supply
+
_
LOAD X
Channel X
