semaphore KINGFISHER PLUS+ - Page 230

Kingfisher Plus+ Hardware Manual
ADP-08-M: Serial Port to Digi External Spread Spectrum Radio
For Digi XTend-PKG or XStream-PKG, and other 3
rd
party radios.
To Kingfisher Serial Port
To External Radio
ADP-09: Serial Port to HITECH or Nematron Display Panel
To Kingfisher Serial Port
To Operators Panel
Hardware Manual Version 7.16
http://www.servelec-semaphore.com/
Page 230
