| 4 - Instruction manual

NOTICE

Damage to the receiver due to incorrect mounting.

The receiver may fall out and be damaged.

▷ The top marking on the mounting frame must not point

downwards.

▷ Insert the receiver into the mounting frame as shown until you hear it click into place.

110
