| 2 - System information
The SL PASC 4 passive antenna splitter
The SL PASC 4 is a passive four-way true diversity antenna splitter/combiner for the
SpeechLine Digital Wireless microphone series. It is used to distribute the antenna signals
from up to 4 SpeechLine Digital Wireless radio links. In combination with the AWM 2 or AWM
4 remote antennas, the number of required antenna cables is reduced to a minimum. The
rack receivers are connected to the SL PASC 4 using the supplied SMA-R cables.
For information about installation and operation, see the instruction manual: The
SL PASC 4 passive antenna splitter/combiner
37
