| 4 - Instruction manual

Meaning of the status LEDs on the charging surfaces

The two blue status LEDs on the charging surfaces provide the following status information:

Flashing normally: the device is charging

Flashing rapidly: excess temperature warning

Flashing/flickering very rapidly: unknown device on the

charger

247
