| 4 - Instruction manual
Meaning of the status LEDs
The four LEDs display status information for the device as a whole or for one of the two or
four microphone channels.
When the LEDs are displaying the status of the entire device and not the individual channels,
all four LEDs (SL MCR 4 DW variant) or the first two LEDs (SL MCR 2 DW variant) will light
up or flash.
The LEDs for each individual channel display status messages for the corresponding radio
connection.
Also note the additional information in the Sennheiser Control Cockpit.
117
