| 4 - Instruction manual
Connecting the receiver
The receiver can output analog and digital audio signals.
The analog audio signal is output via the 3-pin Analog Out terminal.
Digital audio signals are output via the Dante interface with two RJ-45 sockets. This interface
is also used for control and configuration via the network and for Power over Ethernet
supply.
The following variants are possible:
To configure the variants you need the Audinate Dante Controller software:
audinate.com.
