| 3 - System planning
Recommendations on antenna mounting
There are different factors to consider when mounting antennas. This chapter provides
instructions and recommendations that you should follow when mounting antenna.
Antenna setup and planning for SpeechLine Digital Wireless
Antenna mounting options
Option 1: Connecting the AWM 2 or AWM 4 antenna wall mount directly to the
receiver(s)
Option 2: Combining multiple links to one AWM 2/AWM 4
Option 3: Rack mounting - front
Option 4: Rack mounting - rear
Further important information on antenna usage
Antenna setup and planning for SpeechLine Digital Wireless
When planning the installation of SpeechLine Digital Wireless devices for each room,
observe the following guidelines.
▷ Mount all SpeechLine Digital Wireless receivers together in one rack.
▷ Make sure to have a direct line of sight between the transmitters and the receiving
antennas.
▷ Depending on the room characteristics there are several options how to install the
receiving antennas. We recommend the following options in this order:
◦ Option 1: remotely mounted using the AWM 2 for one receiver or the AWM 4
for two receivers. Option 1: Connecting the AWM 2 or AWM 4 antenna wall
mount directly to the receiver(s)
◦ Option 2: remotely mounted using the AWM 2 or AWM 4 and multiple
receivers combined using an antenna splitter (passive splitters SL PASC 2 or
SL PASC 4). Option 2: Combining multiple links to one AWM 2/AWM 4
◦ Option 3: mounted in a rack (front) Option 3: Rack mounting - front
◦ Option 4: mounted in a rack (rear). Option 4: Rack mounting - rear
▷ When mounting antennas remotely, observe the minimum distance to possibly
existing DECT access points and also take into account the cable lengths.
▷ Always switch all receivers on and off with a common power supply (e.g. a multi-
outlet power strip with a central on/off switch) in order to achieve the best
performance of a system.
You can find detailed information about the four antenna mounting options under
Antenna mounting options.
