| 3 - System planning
Option 4: Rack mounting - rear
If you cannot mount the antennas at the front of the rack (option 3), you can also mount them
at the rear of the receiver in the rack. When mounting, observe the following information.
▷ Position the antennas so that they point at a 180-degree angle away from the receiver.
▷ Run all cables close to the receivers to prevent the cables from interfering with the
antenna reception. Use the cable grip.
▷ For best system performance, make sure that the antennas are not covered or
shielded by blocking obstacles such as cables, metal plates, or cases.
▷ In this case, and if possible, make sure that there is a direct line of sight between the
transmitters and the receivers for best possible RF performance.
58
