| 4 - Instruction manual

Is flashing green The Identify function for this channel was initiated in the Control

Cockpit.

The LED of the received transmitter also flashes.

Is yellow The received transmitter has been muted with the MUTE switch.

Is flashing yellow The received transmitter is performing a firmware update.

See Updating the firmware

121
