| 3 - System planning
If possible, group the antennas as follows:
• All A antenna from the receivers’ ANT I sockets in one group according to the
aforementioned requirements
• All B antenna from the receivers’ ANT II sockets in one group according to the
aforementioned requirements
• When using multiple AWM 2/AWM 4 antenna wall mounts, make sure that the
distances between all antennas are equal:
• If possible, position the antennas so that there is a direct line of sight (without
obstacles) between the transmitters and the antennas.
52
