Sharp MX-2314N Service Manual

MX-3114N SIMULATION 6 – 45
43-2
Purpose
Setting
Function (Purpose)
Used to set the fusing temperature in each
mode.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Item/Display Content Setting
value
Default value (SW-A) Default value (SW-B)
Group
A
Group
B
Group
C
Group
A
Group
B
Group
C
A HL_UM READY Ready stanby TH_UM set value 70 - 230 115 130 130 140 140 145
B HL_LM READY Ready stanby TH_LM set value 30 - 200 90 105 105 100 115 115
C HL_US READY Ready stanby TH_US set value 70 - 230 145 150 155 155 160 165
D HL_UM PLAIN PAPER BW Monochrome plain paper TH_UM set value 70 - 230 145 145 155 155 155 165
E HL_LM PLAIN PAPER BW Monochrome plain paper TH_LM set value 30 - 200 110 115 115 115 125 125
F HL_US PLAIN PAPER BW Monochrome plain paper TH_US set value 70 - 230 145 150 155 150 155 160
G HL_UM PLAIN PAPER CL Color plain paper TH_UM set value 70 - 230 145 150 155 160 160 165
H HL_LM PLAIN PAPER CL Color plain paper TH_LM set value 30 - 200 110 115 115 115 125 125
I HL_US PLAIN PAPER CL Color plain paper TH_US set value 70 - 230 145 150 155 155 160 165
J
WARMUP FUMON HL_US
T
Fusing motor pre-rotation start TH_US set
value
30 - 200505050505050
K WARMUP FUMOFF Fusing motor previous rotation complete time 0 - 255 20 20 20 20 20 20
L WARMUP END TIME Warm up complete time 1 - 255 14 14 14 14 14 14
M HL_UM HEAVY PAPER Heavy paper TH_UM set value 70 - 230 180 180 180 180 180 180
N HL_LM HEAVY PAPER Heavy paper TH_LM set value 30 - 200 120 120 120 120 120 120
O HL_US HEAVY PAPER Heavy paper TH_US set value 70 - 230 150 150 150 150 150 150
P HL_UM OHP PAPER OHP TH_UM set value 70 - 230 195 195 195 195 195 195
Q HL_LM OHP PAPER OHP TH_LM set value 30 - 200 125 125 125 125 125 125
R HL_US OHP PAPER OHP TH_US set value 70 - 230 175 175 175 175 175 175
S HL_UM ENV PAPER Envelope TH_UM set value 70 - 230 195 195 195 195 195 195
T HL_LM ENV PAPER Envelope TH_LM set value 30 - 200 125 125 125 125 125 125
U HL_US ENV PAPER Envelope TH_US set value 70 - 230 175 175 175 175 175 175
V HL_UM GLOSS PAPER Gloss paper TH_UM set value 70 - 230 200 200 200 200 200 200
W HL_LM GLOSS PAPER Gloss paper TH_LM set value 30 - 200 120 120 120 120 120 120
X HL_US GLOSS PAPER Gloss paper TH_US set value 70 - 230 180 180 180 180 180 180
Y HL_UM E-STAR Preheating TH_UM set value 30 - 200 110 115 120 110 115 120
Z HL_US E-STAR Preheating TH_US set value 30 - 200 130 130 130 130 130 130
AA HL_UM PRE-JOB Preheat mode restore complete temperature 30 - 200 140 145 150 155 155 160
AB HL_LM E-STAR Preheating TH_LM set value 30 - 200 70 90 90 70 90 90
AC HL_UM HEAVY2 PAPER Heavy paper 2 TH_UM set value 70 - 230 190 190 190 190 190 190
AD HL_LM HEAVY2 PAPER Heavy paper 2 TH_LM set value 30 - 200 120 120 120 120 120 120
AE HL_US HEAVY2 PAPER Heavy paper 2 TH_US set value 70 - 230 160 160 160 160 160 160
AF HL_UM HEAVY3 PAPER Heavy paper 3 TH_UM set value 70 - 230 185 185 185 185 185 185
AG HL_LM HEAVY3 PAPER Heavy paper 3 TH_LM set value 30 - 200 120 120 120 120 120 120
AH HL_US HEAVY3 PAPER Heavy paper 3 TH_US set value 70 - 230 160 160 160 160 160 160
AI HL_UM WARMUP_120L
TH_UM set value when warm up at 120 C or
below
70 - 230 155 160 165 160 165 170
AJ HL_LM WARMUP_120L
TH_LM set value when warm up at 120 C or
below
30 - 200
50 50 50 50 50 50
AK HL_US WARMUP_120L
TH_US set value when warm up at 120 C or
below
70 - 230
135 140 150 150 145 155
AL LO_WARMUP_TIME
Item AI-AK applying time
(Timer from completion of ready)
0 - 255
000000
AM HL_UM WARMUP_120H
TH_UM set value when warm up at 120 C or
above
70 - 230 155 160 165 160 165 170
AN HL_LM WARMUP_120H
TH_LM set value when warm up at 120 C or
above
30 - 200
50 50 50 50 50 50
AO HL_US WARMUP_120H
TH_US set value when warm up at 120 C or
above
70 - 230
135 140 150 150 145 155
AP HI_WARMUP_TIME
Item AM-AO applying time
(Timer from completion of ready)
0 - 255
0
00000
AQ HI_WU_FM_ON_TMP
FM prior rotation start TH_US when warm up
at alpha C or above
30 - 200505050505050
AR HI_WU_END_TIME
Warm up completion time when warm up at
alpha C or above
0 - 255 14 14 14 14 14 14
AS HI_WU_JOB_SET_TMP
Job enable TH_UM temperature when warm
up at alpha C or above
70 - 230 155 160 165 160 165 170

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
