MX-3114N SIMULATION 6 – 108
64-4
Purpose
Operation test/check
Function (Purpose)
Printer test print. (Self print)
Section
Operation/Procedure
1) Set the print conditions.
Select an item to be print condition with scroll keys.
Set the print conditions with 10-key.
Select a target print color with [K] [C] [M] [Y] key.
2) Press [EXECUTE] key.
3) The test print (self print) is performed.
Print pattern of Item A
21 4-point dot print (main
scan)
LSU-ASIC • For every 1/4 of the main scanning direction paper size, print is made for each color.
• When N=0, print of all the background is made in 4 colors.
22 Slant line LSU-ASIC
Pattern No. Content
Pattern generating
section
NOTE
Item/Display Content Setting range Default value
23cpm 26/31cpm
A PRINT PATTERN Specification of the print pattern
(* For details, refer to the description below.)
1 - 6 6 6
B DENSITY Used to specify the print gradation. 1 - 255 128 128
C MULTI COUNT Number of print 1 - 999 1 1
D PAPER MFT Paper feed tray selection Manual paper feed 1 3
(CS2)
3
(CS2)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
LCC LCC 6
E HALFTONE LOW Halftone Low line number 0 0
(LOW)
0
(LOW)
HIGH High line number 1
GLOSSY Glossy paper 2
F QUALITY STANDARD Image quality setting Standard 0 0
(STANDARD)
1
(HIGHQUALITY)
HIGHQUALITY High quality 1
G DITHER STRAIGHT Specification of dither
correction
Straight 0 1
(CALIB)
1
(CALIB)
CALIB Calibration 1
H PAPER TYPE PLAIN Paper type Standard paper 0 0 0
HEAVY Heavy paper 1
HEAVY2 Heavy paper 2 2
GLOSSY Glossy paper 3
HEAVY3 Heavy paper 3 4
Pattern No. Content
1 256 gradations pattern (COLOR)
2 256 gradations pattern (B/W)
3 256 gradations pattern (COLOR) (Y-M-C-K continuous)
4 Halftone pattern (COLOR)
5 Halftone pattern (B/W)
6 Background dot print
