MX-3114N DISASSEMBLY AND ASSEMBLY 10 – 45
(4) Fusing rear unit
a. Transport roller 6
1) Clean the transport roller 6.
(5) Paper exit unit
a. Paper exit roller 1
1) Clean the paper exit roller 1.
b. Discharge brush
1) Remove the holder.
No. Name
1 Transport roller 6
1
No. Name
1 Paper exit roller 1
2 Discharge brush
1
2
