Sharp MX-2314N Service Manual

MX-3114N ADJUSTMENTS AND SETTINGS 5 – 44
10-D Copy / Image send / FAX image quality
adjustment (Individual adjustment)
a. General
This adjustment is used to execute the fine adjustment in each mode only when a satisfactory image quality is not obtained by the basic adjust-
ments ADJ 10B and ADJ 10C or there is a request from the user. Normally there is no need to execute this adjustment.
In this adjustment, the adjustment result may be applied to the image send mode and the FAX mode as well as the copy mode.
This must be well understood for execution of the adjustment.
Copy MODE IMAGE SEND(SCAN) MODE
Color mode
Monochrome
mode
Color mode
Monochrome
mode
Auto Manual Auto Manual Auto Manual Auto Manual FAX Printer
46-01 Color copy density adjustment (for each
color copy mode) (separately for the low-
density area and the high-density area)
(No need to adjust normally)
 ------ - -
46-02 Monochrome copy density adjustment (for
each monochrome copy mode) (separately
for the low-density area and the high-density
area) (No need to adjust normally)
-- ---- - -
46-04 Color image send mode image density
adjustment (for each mode)
(No need to adjust normally)
---- -- - -
46-05 Monochrome image send mode image
density adjustment (for each mode)
(No need to adjust normally)
------ --
46-08 Image send mode RGB color balance
adjustment (separately for the low-density
area and the high-density area)
(No need to adjust normally)
---- -- - -
46-09 RSPF mode (Copy/Scan/FAX) density
adjustment (No need to adjust normally)
   -
46-10 Color copy color balance, gamma
adjustment (for each color copy mode)
(No need to adjust normally)
 ------ - -
46-16 Monochrome copy density, gamma
adjustment (for each monochrome copy
mode) (No need to adjust normally)
-- ---- - -
46-19 Automatic monochrome (Copy/Scan/FAX)
mode document density scanning operation
(exposure operation) conditions setting
(Normally no need to set)
-- --- -  -
46-21 Copy color balance and density adjustment
(Manual adjustment)
 ---- - -
46-23 Copy high density image density
reproduction setting (Normally unnecessary
to the setting change)
 ---- - -
46-24 Copy color balance and density adjustment
(Automatic adjustment)
 ---- - -
46-25 Copy color balance adjustment (Single color
copy mode) (No need to adjust normally)
-  ------ - -
46-26 Single color copy mode color balance
default setting
-  ------ - -
46-27 Color copy, text, line image reproduction
adjustment (edge gamma, density
adjustment) (Text, Map mode)
(No need to adjust normally)
 ------ - -
46-30 Copy mode sub scanning direction
resolution setting
 ------ - -
46-32 Document low density image density
reproduction adjustment in the automatic
monochrome (Copy/Scan/FAX) mode
(No need to adjust normally) (Background
density adjustment in the scanning section)
-- --- -  -
46-36 2-color (red, black) copy mode fine color
adjustment (No need to adjust normally)
-  ------ - -
46-37 Monochrome (Copy/Scan/FAX) mode color
document reproduction adjustment
(No need to adjust normally)
-- --
  (*3)(*5)
46-38 Color copy mode dark area gradation (black
component quantity) adjustment
(No need to adjust normally)
 ------ - -
46-39 FAX send image sharpness adjustment - - - - - - - -  -
46-40 FAX send image density adjustment
(Collective adjustment of all the modes)
--------  -

Sharp MX-2314N Specifications

General

Print Technology	Laser
Print Speed	23 ppm
Print Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Copy Speed	23 cpm
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Duplex Printing	Yes
Connectivity	USB, Ethernet
Functions	Print, Copy, Scan, Fax
Paper Size	A3, A4, A5, B4, B5
Max Paper Size	A3
Original Size	A3
