Sharp MX-2314N Service Manual

MX-3114N ADJUSTMENTS AND SETTINGS 5 – 46
10-D (1)
Color copy density adjustment (for each
color copy mode) (separately for the low-
density area and the high-density area)
(No need to adjust normally)
The density is adjusted in each copy mode individually.
This adjustment must be performed in the following cases:
* When there is necessity to change the copy density of the low
density and high density part at each copy density individually.
* When there is necessity to change the density gradient of the
copy by each the copy mode individually.
* When there is necessity to change all copy density by each the
copy mode individually.
* When there is request from the user.
1) Enter the SIM 46-1 mode.
2) Select the copy mode to be adjusted with the scroll key.
㩷
OK
㪈㪇㪄㫂㪼㫐
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(;32685($'-8670(17&2/25>&23<@


$˖
˷˹
˖$872
$˖
˖7(;7
%˖
˖7(;735,17('ǂ3+272
&˖
˖7(;73+272
'˖
˖3+272*5$3+
)˖
˖35,17('ǂ3+272
(˖
˖0$3
*˖
˖/,*+7
+˖
˖7(;7&23<ǂ72ǂ&23<
,˖
˖7(;735,17('ǂ3+272&23<ǂ72ǂ&23<
-˖
˖35,17('ǂ3+272&23<ǂ72ǂ&23<
.˖
˖7(;7&2/25ǂ721(ǂ(1+$1&(0(17
/˖
2.
+,*+/2:
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(;32685($'-8670(17&2/25>&23<@


$˖
˷˹
˖$872
$˖
˖7(;7
%˖
˖7(;735,17('ǂ3+272
&˖
˖7(;73+272
'˖
˖3+272*5$3+
)˖
˖35,17('ǂ3+272
(˖
˖0$3
*˖
˖/,*+7
+˖
˖7(;7&23<ǂ72ǂ&23<
,˖
˖7(;735,17('ǂ3+272&23<ǂ72ǂ&23<
-˖
˖35,17('ǂ3+272&23<ǂ72ǂ&23<
.˖
˖7(;7&2/25ǂ721(ǂ(1+$1&(0(17
/˖
2.
+,*+/2:
Display/Item Content
Setting
range
Default
A AUTO Auto LOW 1 - 99 50
HIGH 1 - 99 50
B TEXT Text LOW 1 - 99 50
HIGH 1 - 99 50
C TEXT/PRINTED
Text/Printed
LOW 1 - 99 50
HIGH 1 - 99 50
D TEXT/PHOTO Text/Photograph LOW 1 - 99 50
HIGH 1 - 99 50
E PRINTED PHOTO Printed Photo LOW 1 - 99 50
HIGH 1 - 99 50
F PHOTOGRAPH Photograph LOW 1 - 99 50
HIGH 1 - 99 50
G MAP Map LOW 1 - 99 50
HIGH 1 - 99 50
H LIGHT Light document LOW 1 - 99 50
HIGH 1 - 99 50
ITEXT
(COPY TO COPY)
Text (Copy
document)
LOW 1 - 99 50
HIGH 1 - 99 50
J TEXT/PRINTED
(COPY TO COPY)
Text/Printed
Photo (Copy
document)
LOW 1 - 99 50
HIGH 1 - 99 50
K PRINTED PHOTO
(COPY TO COPY)
Printed Photo
(Copy document)
LOW 1 - 99 50
HIGH 1 - 99 50
LTEXT
(COLOR TONE
ENHANCEMENT)
Text
(Color tone
enhancement)
LOW 1 - 99 50
HIGH 1 - 99 50
M TEXT/PRINTED
(COLOR TONE
ENHANCEMENT)
Text/Printed
(Color tone
enhancement)
LOW 1 - 99 50
HIGH 1 - 99 50
N TEXT/PHOTO
(COLOR TONE
ENHANCEMENT)
Text/Photograph
(Color tone
enhancement)
LOW 1 - 99 50
HIGH 1 - 99 50
O PRINTED PHOTO
(COLOR TONE
ENHANCEMENT)
Printed Photo
(Color tone
enhancement)
LOW 1 - 99 50
HIGH 1 - 99 50
P PHOTOGRAPH
(COLOR TONE
ENHANCEMENT)
Photograph
(Color tone
enhancement)
LOW 1 - 99 50
HIGH 1 - 99 50
QMAP
(COLOR TONE
ENHANCEMENT)
Map
(Color tone
enhancement)
LOW 1 - 99 50
HIGH 1 - 99 50
R SINGLE COLOR Single color LOW 1 - 99 50
HIGH 1 - 99 50
S SINGLE COLOR
(COPY TO COPY)
Single color
(Copy document)
LOW 1 - 99 50
HIGH 1 - 99 50
T TWO COLOR Two-color
(Red/Black) copy
LOW 1 - 99 50
HIGH 1 - 99 50
U TWO COLOR
(COPY TO COPY)
Two-color
(Red/Black) copy
(Copy document)
LOW 1 - 99 50
HIGH 1 - 99 50
