Shihlin electric SF-GT Series User Manual

Parameter Description
Parameters
106
Parameter
Factory
setting
Setting
range
Remarks
54 0 0~5
0
Output frequency, the frequency display
reference P.55 is 100%.
1
Output current, the current monitoring
reference P.56 is 100%.
2
Output DC bus voltage, the OV level is 100%.
3
Output the temperature rising accumulation rate of
inverter, the NTC level is 100%.
4
Output the electronic thermal rate of the inverter, the
electronic thermal relay running (when P.9≠0) or the
electronic thermal relay of the inverter’s IGBT
module running (when P.9=0) is 100%.
5
Output setting frequency, the frequency display
reference P.55 is 100%.
55
50Hz
0~650Hz
P.189=1
60Hz
P.189=0
56
Rated
current
0~500A ---
64 0 0~3
0
AM function, 0~10V voltage can be output across
terminal AM1-5.
1
The terminal HDO output function
2
AM function, 0~20mA current can be output across
terminal AM1-5.
3
AM function, 4~20mA current can be output across
terminal AM1-5.
74 0 0~9000
0
Select FM function as the output function of terminal
HDO
1~
90
00
Select the square-wave pulse which is P.74 times of
running frequency as the output of terminal HDO
187
---
0~9998
The factory adjusted value
190
---
0~2500
The factory adjusted value
191
---
0~2500
The factory adjusted value
<Setting>
• The current/voltage output of terminal AM1 is set by both the toggle switch SW6 on control
board and P.64. When the user need to select the output type of terminal AM1, please turn
the toggle switch SW6 to the corresponding type at first and then set the value of P.64
• When P.74=0 and P.64=1, the terminal HDO select FM function, wiring shown as figure 6,
Which displays the output current or frequency of the inverter.
• The output of the terminal AM1 and the output of the terminal HDO with FM function are
shown as follows:
