Parameter Description
(P.611).
• P.617 is used to set the curling radius filtering coefficient to avoid fast change of curling
radius calculation (or input) result.
• P.618 is used to display the current curling radius in real time. It is able to know the current
actual curling radius through the parameter.
• Only when P.610=1 or P.610=2, the parameters P.619~P.626 are related to the parameter.
1) P.619 represents pulse number when winding shaft turns a round. It needs to be set
when P.610=2.
2) P.612 shows the rounds of winding shaft turning after the material wraps one layer. It is
used for wire.
3) When the material thickness is analog input (P.621=1), the maximum analog input
corresponds to the set value of P.626.
4) When P.621 =0, the system default material thickness is determined by the parameter
P.622. The different material thickness source can also be selected by the
combination of external terminals and P.622~P.625, the selection relationship is as
follows:
• When P.650 =0, it does not memorize the curling radius when you turn off the power or stop
calculating the curling radius, and it takes curling radius(P.612) or original curling
radius(P.614) as initial value of calculation when you re-turn on the power or begin to
calculate. When P.650 =1, it memorizes previous calculation value to P.618 when you turn off
the power or stop calculating the curling radius, and it takes the memorized curling radius as
initial value when you re-turn on the power or begin to calculate.
