Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
211
Parameter
Number
Name Setting Range
Minimum
Setting Unit
Default Value
User
Setting
Value
Reference
Page
P.511
The setting corresponding
to the
maximum negative voltage of
terminal 2-5
-
100.0%~100.0% 0.1%
0.0%
P147
P.512
The minimum input negative
voltage of terminal 2-5
0~10V 0.01V 0 V P147
P.513
The maximum input negative
voltage of terminal 2-5
0~10V 0.01V 0 V
P147
P.514
The setting corresponding to the
minimum positive voltage of
terminal 1
-5
-100%~100% 0.1% 0% P154
P.515
The setting corresponding to the
maximum positive voltage o
f
terminal 1-5
-100%~100% 0.1% 100%
P154
P.516
The minimum input positive
voltage of terminal 1-5
0~10V 0.01V 0 V P154
P.517
The maximum input positive
voltage of terminal 1-5
0~10V 0.01V
5V
P154
P.518
The setting corresponding to the
minimum negative voltage of
terminal 1
-5
-100%~100% 0.1% 0%
P154
P.519
The setting corresponding to the
maximum negative voltage of
terminal 1-5
-100%~100% 0.1%
0%
P154
P.520
The minimum input negative
voltage of terminal 1-5
0~10V 0.01V 0 V
P154
P.521
The maximum input negative
voltage of terminal 1-5
0~10V 0.01V 0 V
P154
P.522
The setting c
orresponding to the
minimum frequency of terminal
HDI
-100%~100% 0.1% 0%
P178
P.523
The setting corresponding to the
maximum frequency of terminal
HDI
-100%~100% 0.1% 100%
P178
P.524
The minimum input f
requency of
terminal HDI
0~100kHz 0.01kHz 0 kHz
P178
P.525
The maximum input frequency of
terminal HDI
0~100kHz 0.01kHz 100kHz
P178
P.526
The HDI filter coefficient
0~31 1 1
P178
P.528
4
-5 Input signal filter constant
0~2047
1 31
P111
