Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
212
Parameter
Number
Name Setting Range
Minimum
Setting Unit
Default Value
User
Setting
Value
Reference
Page
P.529
1
-5 Input signal filter constant
0~2047
1 31
P111
P.530
The selection of voltage signal
across terminal 1
-5
0~5 1 0 P101
P.532
PTC filter coefficient
0~31 1 31
P179
P.533
The process mode selection
of PTC alarm
0~3 1 0
P179
P.534
The percentage of PTC level
0~100% 0.1% 0%
P179
P.535
AM2
output bias
0~2500 1 ---
P109
P.536
AM2 output gain
0~2500 1 --- P109
P.537
AM2 terminal function
selection
0~5
1 0 P109
P.538
AM2 output terminal selection
0,2,3
1
0
P109
P.550
Multi
-function terminal HDI
function selection
0~41，43~57 1 57 P120
P.600
The tension control mode
selection
0~4 1 0
P179
P.601
The curling mode
0~1 1 0
P179
P.602
Selection of inverse take
-up
during roll
-down
0~1 1 0
P179
P.603
Mechanical transmission ratio
0.01～300 0.01 1.00 P179
P.604
Tension setting source
0~2
1
0
P181
P.605
Tension setting
0~30000N 1 N 0 N
P181
P.606
Maximum tension
0~30000N 1 N 0 N P181
P.607
Zero-speed tension increase
0.0%~50.0%
0.1%
0.0%
P181
P.608
Zero
-speed threshold
0~30Hz 0.01 Hz 0 Hz
P181
P.609
Tension taper
0.0%~100.0% 0.1% 0.0% P181
P.610
curling radius calculation method
selection
0~3 1 0
P182
P.611
Maximum curling radius
1~10000mm
1 mm
500 mm
P182
P.612
Winding shaft diameter
1~10000mm 1 mm 100 mm
P182
