Shihlin electric SF-GT Series User Manual

Appendix 1 Parameter Table
Parameter Table
213
Parameter
Number
Name Setting Range
Minimum
Setting Unit
Default Value
User
Setting
Value
Reference
Page
P.613
Initial curling radius source
0~1
1
0
P182
P.614 Initial curling radius 1
1~10000mm 1 mm 100 mm
P182
P.615
Initial curling radius 2
1~10000mm
1 mm
100 mm
P182
P.616 Initial curling radius 3 1~10000mm 1 mm 100 mm P182
P.617
Curling radius filtering
coefficient
0~31 1 0 P182
P.618 Current value of curling radius
0~10000mm
1 mm ---
P182
P.619
Number of pulses each turn
1~60000
1
1
P182
P.620 Number of turns each layer
1~10000 1 1
P182
P.621
Material thickness setting
source
0~1 1 0 P182
P.622 Material thickness 0
0.01~100.00mm 0.01 mm 0.01 mm
P182
P.623
Material thickness 1
0.01~100.00mm
0.01 mm
0.01 mm
P182
P.624 Material thickness 2
0.01~100.00mm 0.01 mm 0.01 mm
P182
P.625 Material thickness 3
0.01~100.00mm 0.01 mm 0.01 mm
P182
P.626
Maximum thickness
0.01~100.00mm
0.01 mm
1.00 mm
P182
P.627 Line speed input source
0~2 1 0
P186
P.628 Maximum line speed
0.1~6500.0m/min 0.1m/min
1000.0m/min
P186
P.629
Minimum line speed for
curling radius calculation
0.1~6500.0m/min 0.1m/min 200.0m/min
P186
P.630
Actual line speed
0~6500.0m/min
0.1m/min
---
P186
P.631
Inertia self learning torque
setting 1
0.0%~P.632
0.1% 30% P187
P.632
Inertia self learning torque
setting 2
P.631~100%
0.1% 60%
P187
P.633
Mechanical inertia
compensation coefficient
0~65535
1 0 P187
P.634 Material density
0kg/m
3
~60000kg/m
3
1 kg/m
3
0 kg/m
3
P187
P.635 Material width
0~60000mm
1mm 0mm
P187
P.636
Fiction compensation
coefficient
0.0%~50.0%
0.1 0 P187
P.637
Material supply interrupt auto
detection function selection
0~1 1 0
P188
P.638
Material supply interrupt auto
detection minimum line speed
0.1~6500.0m/min 0.1m/min 200m/min
P188
P.639
Material supply interrupt auto
detection error range
0.1%~50.0% 0.1% 10.0% P188
