Shimadzu GC-2014 Service Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
29
2.3.2 Function of Each Board
 CPU Unit, GC-2014
Central processor
 Power Unit
This unit detects the temperature of the oven, detector, and injection port, and regulates
the temperature of each part by controlling the heater current. It also controls the CRG,
high speed cooling unit, and AOC power switching.
 Controller for Detectors
This unit converts the detector signal readout to a digital value, and outputs the value to
the CPU unit.
 PCB AUX TEMP
This auxiliary unit is used when there are not enough power unit temperature control
connectors.
 PCB KEY ASSY, GC-2014
This unit receives the window display signal from the CPU unit, and outputs the signal to
the LCD. This unit also outputs the key signal input to the CPU.
 PCB DET I/F GC-2014
This is the relay board for the power boards.
 PCB FLOW I/F GC-2010
This is the relay board for the AFC, APC, and CPU unit.

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
