Shimadzu GC-2014 Service Manual

Chapter 6 Maintenance Parts List
GC-2014 Service Manual
70

DFID
P/N Description Previous P/N Compatibility Remarks
S221-70040-41 FID-2014 CONTROLLER, DUAL S221-70040-91
S221-75085-41 DET HEATER ASSY, F, 100 V S221-70085-91

S221-75085-42 DET HEATER ASSY, F, 115 V S221-70085-92

S221-75085-44 DET HEATER ASSY, F, 230 V S221-70085-34


WBI-2014
P/N Description Previous P/N Compatibility Remarks
S221-73335-44 AFC-2014,D-PURGE,WBI S221-47735-94


SINJ
P/N Description Previous P/N Compatibility Remarks
221-75081-81 PACKED SINGLE INJ, 100 V S221-70081-81

221-75081-84 PACKED SINGLE INJ, 230V S221-70080-83


DINJ
P/N Description Previous P/N Compatibility Remarks
S221-75075-41 DUAL AFC ASSY S221-70075-91

S221-75080-81 DUAL INJ, STOCKED, 100 V S221-70080-81

S221-75080-82 DUAL INJ, STOCKED, 115 V S221-70080-82

S221-75080-83 DUAL INJ, STOCKED, 230 V S221-70080-38

S221-70466 FIN, 2014

S221-22206 SPACER, INJ


Others
P/N Description Previous P/N Compatibility Remarks
S221-18150-41 N BELLOW VALVE, 2K S221-18150-91

S221-41511-41
N BELLOW VALVE 2K, WITH
RESISTANCE
S221-41511-91

S221-70483-91 SOLENOID VALVE ASSY

For FID, FPD flow controller
S221-73356-91 HYDROGEN TUBE ADAPTER -
For conversion from
right-hand thread to left-hand
thread


Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
