Shimadzu GC-2014 Service Manual

Chapter 6 Maintenance Parts List
GC-2014 Service Manual
69

FTD-2014 Capillary
P/N Description Previous P/N Compatibility Remarks
S221-46520-42 FID-2014 CONTROLLER S221-46520-92

S221-48457-42 FTD-2010 POWER CONTROLLER S221-48457-92

S221-21910 INSULATOR, CERAMIC

S221-75116-81 FOR FID FTD2014C, 100 V N/A

FID 100-V system
S221-75116-84 FOR FID FTD2014C, 230 V N/A

FID 200-V system
S221-47658-91 FID BASE UNIT, ASSY, FTD

S221-75049-82 FLOW CONTROLLER, H2-AIR-FTD S221-70049-92

Changed to left-hand thread
specifications
S201-48386 3-WAY SPLIT TUBING, M-TYPE

S221-18713-95 RESISTANCE TUBE ASSY, H2

For FTD
S221-18713-96 RESISTANCE TUBE ASSY, AIR FTD-9

For FTD
S221-19502-08 RESISTANCE TUBE, H2

Resistance tube only (for
make-up)
S221-31745 HOUSING, RESISTANCE TUBE

S221-73473-91
BRANCHED PIPE, L, MM-MF-MF
(LEFT-HAND THREAD)

S221-41532-92 GRAPHITE POSITIONING JIG, FID


FTD-2014 Packed
P/N Description Previous P/N Compatibility Remarks
S221-46520-42 FID-2014 CONTROLLER S221-46520-92

S221-48457-42 CONTROLLER, FTD-2014 S221-48457-92

S221-70298-91 BASE UNIT, ASSY, FID

S221-70662 FTD CABLE PACKING

Collector cover packing
S221-75088-41 FID-2014 HEATER ASSY, 100 S221-70610-91

S221-75088-44 FID-2014 HEATER ASSY, 230 S221-70610-34

S221-75049-82 FLOW CONTROLLER, H2-AIR-FTD S221-70049-92

Changed to left-hand thread
specifications
S201-48386 3-WAY SPLIT TUBING, M-TYPE

S221-18713-95 RESISTANCE TUBE ASSY, H2

For FTD
S221-18713-96 RESISTANCE TUBE ASSY, AIR FTD-9


ECD-2014
P/N Description Previous P/N Compatibility Remarks
S221-48455-42 ECD-2014 CONTROLLER S221-48455-92

S221-74687-41 ECD-2014 HEATER ASSY, 100 S221-70623-91

FID 100-V system
S221-74687-44 ECD-2014 HEATER ASSY, 230 S221-70623-34

FID 200-V system
S221-75049-44 FLOW CONTROLLER, AUX S221-70049-94

S221-19502-08 RESISTANCE TUBE, H2

Resistance tube only (for
make-up)
S221-31745 HOUSING, RESISTANCE TUBE

S221-33193-91 CAPILLARY ADAPTER, DET SIDE


TCD-2014
P/N Description Previous P/N Compatibility Remarks
S221-70041-41 TCD-2014 CONTROLLER S221-70041-91

S221-70043-91 TCD POWER SUPPLY

S221-75098-81 TCD CELL ASSY, 100 V S221-70098-81

S221-75098-82 TCD CELL ASSY, 115 V S221-70098-82

S221-75098-84 TCD CELL ASSY, 230 V S221-70098-38

S221-74600-41 TCD 100 OHM, 2014+ S221-70744-91

S221-75086-41 DET HEATER ASSY, FT, 100 S221-70086-91

S221-75086-42 DET HEATER ASSY, FT, 115 S221-70086-92

S221-75086-44 DET HEATER ASSY, FT, 230 S221-70086-34




Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
