Chapter 3 Gas-Flow Controller
GC-2014 Service Manual
41
3.1.2.4 AUX
Reference No.
S221-75049-44 11 S221-18150-43
FLOW CONTROLLER, AUX
1PC
N BELLOW VALVE, 2K, 8KIN
16 S080-53043-01
2PC
PRESSURE GAUGE, 200 kPa
17 S018-21330
TAPE, STICKER, 0.1
13
5
25 S221-31745
1PC
HOUSING
26 S221-23391-91
1PC
REPLACEMENT
27 S201-35584
1PC
REPLACEMENT
28 S221-09864-18
1PC
PIPE, MF-MM17, 2
180
29
1PC
37 S201-48557-25
1PC
PIPE, MN2W-MM2W
RUBBER PLUG, INJECTION PORT,
SILICONE
PIPE, PG-MF-MF ASSY
RESISTANCE TUBE, HYDROGEN, GC-8A
AUX
H
2
resistance tube: (26)
Insert with rubber plug for port (27).
