Shimadzu GC-2014 - Ecd

Chapter 5 Detector Unit
GC-2014 Service Manual
55
5.3 ECD
Radiation warning sign
Mechanism check sign
Electrode
Hermetic sticker
Heater ASSY
Capillary adapter
(ECD)
ECD cel
l body
Radiation source
Nut M10 cell
fixing
Make-up gas inlet
(Purge gas)
To vent
