Shimadzu GC-2014 Service Manual

Chapter 5 Detector Unit
GC-2014 Service Manual
56
Configuration Diagram for ECD
221-25055-91
ECD-9 (ECD cell)
ECD cell
S221-75032-44 S020-46147
ECD-2014, CONTROLLER, 230
1PC
3PC
SCREW, SUS, SEMS, P2 M4

8
S221-75032-41 S221-40578 (-40579 EN) S023-66140-01
ECD-2014, CONTROLLER, 100
1PC
INSTRUCTION MANUAL, ECD-2010J
3PC
WASHER, PLAIN, SUS 4
S221-75032-42
S221-40580 (-40581 EN)
S020-46534
ECD-2014, CONTROLLER, 115
1PC
INSTALLATION, ECD-2010J
1PC
SCREW, SUS, SEMS, P3, M3

6
S221-74687-41 (-44) S221-46547
1PC
ECD-2014 HEATER ASSY, 100 (230)
2PC
SCREW, SUS, SEMS, P3, M4

8
S221-48455-42 S020-09688-91
1PC
CONTROLLER, ECD-2010J
1PC
PIPE, AIR IN
S221-75049-44
S221-70115
1PC
FLOW CONTROLLER, AUX
1PC
ECD HEAT RETAINING BLOCK 1
201-42870 (221-07755 EN)
S221-70883
1PC
RI, NAMEPLATE
1PC
MOUNTING PLATE, DET, SINGLE, CENTER
S221-00816-04
1PC
1PC
SIGNAL CABLE, AS, ECD-2014
1PC 1PC
1PC
S221-70383
1PC
NUT, M10, CELL FIXING
S221-32705
1PC
CAP NUT, M5

0.5, SLOTTED
S221-33193-91
1PC
CAPILLARY ADAPTER, DET SIDE
S221-41532-99
1PC
GRAPHITE JIG, ECD-2014
S202-58258-02
1PC
JOINT, GL-GN, 20.5MT
S201-48560-05
1PC
PIPE, MF-GF 50
S201-32069
1PC
WASHER
S201-48464
1PC
NUT M8
S221-34121-94
1PC
MS FILTER, CONDITIONING
1PC
1PC
S070-41154
1PC
CONNECTOR, UG-306/V (40)
CABLE TIE, T30R
ACCESSORY, ECD-2014
NAMEPLATE, ECD VENT
LABEL, ECD CAUTION ECD ACCESSORY, GC-7A
HEAT INSULATING MATERIAL, DET-S, BUILT-IN
ADHESIVE NAMEPLATE, MAKEUP

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
