Shimadzu GC-2014 Service Manual

Chapter 3 Gas-Flow Controller
GC-2014 Service Manual
33
Chapter 3 Gas-Flow Controller
3.1 Configuration Diagrams for Gas-Flow Controller
3.1.1 AFC
There are four types of AFC: for packed dual injection, split/splitless injection, WBI (direct),
and packed single injection.
DAFC Dual Packed INJ (Assembly Configuration Chart)
AFC_Split/Splitless INJ (Assembly Configuration Chart)
AFC_WBI (Direct) (Assembly Configuration Chart)
S221-75075-41
DUAL AFC
S221-48813-91
VALVE ASSY
DIFFERENTIAL PRESSURE SENSOR ASSY, LONG
FLOW BOARD ASSY, DUAL
PCB ASSY, D-AFC
DIFFERENTIAL PRESSURE SENSOR ASSY
PCB ASSY,
D-AFC-2014
PIPING ASSY
S221-73335-43
AFC-2014+, SPL
S221-46812-91
PIPING ASSY
S221-48813-91
VALVE ASSY
DIFFERENTIAL PRESSURE SENSOR ASSY
FLOW BOARD ASSY AFC2
PCB ASSY, AFC-2010+
PCB, AFC3
GC-2010+
S221-73335-44
AFC-2014+, WBI
S221-48625-91
PIPING ASSY WBI
S221-48813-91
VALVE ASSY
DIFFERENTIAL PRESSURE SENSOR ASSY
FLOW BOARD ASSY, AFC2
PCB ASSY, AFC-2010+ PCB, AFC3 GC-2010+
"-81" for maintenance

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
