Shimadzu GC-2014 Service Manual

Chapter 6 Maintenance Parts List
GC-2014 Service Manual
68
FID-2014 Single
P/N Description Previous P/N Compatibility Remarks
S221-46520-42 FID-2014 CONTROLLER S221-46520-92

S221-70090-91 FID-2014 CELL ASSY, C

S221-70298-91 BASE UNIT, ASSY, FID

S221-47146-92 HIGH-VOLTAGE ELECTRODE, FID-2014

S221-47659-92 COLLECTOR ASSY, FID

S221-21910 INSULATOR, CERAMIC

For FID collector
S221-75088-41 FID-2014 HEATER ASSY, 100 S221-70610-91

FID 100-V system
S221-75088-44 FID-2014 HEATER ASSY, 230 S221-70610-34

FID 200-V system
S221-75049-81 FLOW CONTROLLER, H2-AIR, FID S221-70049-91

Changed to left-hand thread
specifications
S221-19503-08 RESISTANCE TUBE, AIR

Resistance tube only (for air)
S221-19502-08 RESISTANCE TUBE, H2

Resistance tube only (for
make-up)
S221-31745 HOUSING, RESISTANCE TUBE

S201-48386
3-WAY SPLIT TUBING, M-TYPE
(MM-MF-MF)

S221-73473-91
BRANCHED PIPE, L, MM-MF-MF
(LEFT-HAND THREAD)

For hydrogen (left-hand
thread)
S221-41532-98 GRAPHITE POSITIONING JIG, FID-2014


FPD-2014
P/N Description Previous P/N Compatibility Remarks
S221-48456-42 FPD-2014 CONTROLLER S221-48456-92

S221-73412-41 BATTERY BOX ASSY, FPD S221-48355-91

S221-70100 BATTERY COVER

S221-48578 PHOTOMULTIPLIER, R5983

S221-48419-92 SOCKET ASSY, FPD

S221-70653-41 FAN BASE, ASSY, FPD+ N/A

Auxiliary
S221-70778-41 FAN ASSY, FPD S221-70778-91

For filter cooling
S221-70777-41 THERMISTOR ASSY, 2014+ N/A

Auxiliary
S221-70495-91 BODY ASSY

Combustion chamber
S221-70110 BODY, UPPER, FPD-2014

Igniter block
S221-70356 SHIELD RING ADJUSTER 1

S221-70357 SHIELD RING ADJUSTER 2

S221-23007 SET SCREW, SILICA TUBE

S221-33193-91 CAPILLARY ADAPTER, DET SIDE

S221-41532-90 GRAPHITE JIG, FPD 2014

S221-75117-41 FPD-2014, HEATER UNIT, 100 N/A

FPD 100-V system
S221-75117-44 FPD-2014, HEATER UNIT, 230 S221-70617-34

FPD 200-V system
S221-75049-83 FLOW CONTROLLER, H2-AIR, FPD S221-70049-93

Changed to left-hand thread
specifications
S221-19502-08 RESISTANCE TUBE, H2

Resistance tube only (for H2)
S221-31745 HOUSING, RESISTANCE TUBE

S201-48386 BRANCHED PIPE, MM-MF-MF

S221-73473-91
BRANCHED PIPE, L, MM-MF-MF
(LEFT-HAND THREAD)


